20 TOOTH CLUTCH DRIVE GEAR – STANDARD ON T5 MODELS
£32.80 (including VAT)
VE11107-20 Clutch drive gears with a 108mm backing plate for use in the old 7 spring clutches - 20 Tooth. These drive gears are available in 20 tooth as fitted to T5 models, 21 tooth as fitted to Cosa 200 mark 1 models, 22 tooth as fitted to the Rally 180, and 23 tooth as fitted to P200E-PX200E models. Changing the drive gear tooth count can raise or lower the overall gearing, (less teeth will lower the gearing, more teeth will increase the gearing) and is really easy to do as only the clutch needs removing from the motor, ideal if you are tuning your motor or pulling a side car. This drive gear is 20 tooth, and it has 26 teeth where the clutch steel plates fit, it is 32mm tall and the backing plate is 108mm, this will mate with 67 & 68 tooth drive gears. Equivalent to Piaggio Vespa number 241346. Fitment VESPA 125 - T5 125 1986-1990 VESPA 125 - T5 125 CLASSIC 1991-2000
Fitment Chart
| LML | LML STAR 125 2 STROKE | 20 TOOTH CLUTCH DRIVE GEAR - STANDARD ON T5 MODELS |
| LML | LML STAR 125 4 STROKE MANUAL | 20 TOOTH CLUTCH DRIVE GEAR - STANDARD ON T5 MODELS |
| LML | LML STAR 150 4 STROKE MANUAL | 20 TOOTH CLUTCH DRIVE GEAR - STANDARD ON T5 MODELS |
| VESPA | VESPA 125 - T5 125 1986-1990 | 20 TOOTH CLUTCH DRIVE GEAR - STANDARD ON T5 MODELS |
| VESPA | VESPA 125 - T5 125 CLASSIC 1991-2000 | 20 TOOTH CLUTCH DRIVE GEAR - STANDARD ON T5 MODELS |
| VESPA | VESPA 200 COSA | 20 TOOTH CLUTCH DRIVE GEAR - STANDARD ON T5 MODELS |
