22 TOOTH CLUTCH DRIVE GEAR – STANDARD ON P125X MODELS
£26.20 (including VAT)
VE11187-22 CLUTCH DRIVE GEAR 22 TOOTH - 6 SPRING CLUTCH ONLY. Clutch drive gears with a 96mm backing plate for use in the old 6 spring clutches, these are available in 20 tooth as fitted to later PX EFL models, 21 tooth PX as fitted to PX125E and early EFL models, and 22 tooth as fitted to P125X models. Changing the drive gear tooth count can raise or lower the overall gearing, (less teeth will lower the gearing, more teeth will increase the gearing) and is really easy to do as only the clutch needs removing from the motor, ideal if you are tuning your motor or pulling a side car. This drive gear is 22 tooth, and it has 26 teeth where the clutch steel plates fit, it is 32mm tall and the backing plate is 96mm. Equivalent to Piaggio Vespa numbers 113069. Fitment LML STAR 125 2 STROKE VESPA 125 - PX125EFL 1984-1997 VESPA 125 COSA VESPA 125 - P125X 1978-1981 VESPA 125 - PX125E 1981-1984 VESPA 150 - P150X 1978-1981 VESPA 150 - PX150E 1981-1984
Fitment Chart
LML | LML STAR 125 2 STROKE | 22 TOOTH CLUTCH DRIVE GEAR - STANDARD ON P125X MODELS |
VESPA | VESPA 125 - P125X 1978-1981 | 22 TOOTH CLUTCH DRIVE GEAR - STANDARD ON P125X MODELS |
VESPA | VESPA 125 - PX125E 1981-1984 | 22 TOOTH CLUTCH DRIVE GEAR - STANDARD ON P125X MODELS |
VESPA | VESPA 125 - PX125EFL 1984-1997 | 22 TOOTH CLUTCH DRIVE GEAR - STANDARD ON P125X MODELS |
VESPA | VESPA 125 COSA | 22 TOOTH CLUTCH DRIVE GEAR - STANDARD ON P125X MODELS |
VESPA | VESPA 150 - P150X 1978-1981 | 22 TOOTH CLUTCH DRIVE GEAR - STANDARD ON P125X MODELS |
VESPA | VESPA 150 - PX150E 1981-1984 | 22 TOOTH CLUTCH DRIVE GEAR - STANDARD ON P125X MODELS |
