MALOSSI 150mm CLUTCH BELL

£121.94 (including VAT)


VB777969
Stock : Coming Soon


VB617969 MALOSSI CLUTCH BELL 150mm - SUZUKI BURGMAN 400 upto 2007.Clutch Bell with Reinforced Cooling Ring. The clutch bells with reinforced cooling ring consist of a finned annular reinforcement producing excellent heat dissipation caused primarily from stand still starts and quick accelerations from low speeds. This technological innovation resulted from extensive testing within the Scooter racing circuit. The clutch bell design is based on the following principals: greater heat transfer surface area (finned section) lowers the working temperature of the clutch bell which dramatically increases the systems durability. The clutch system is enormously stressed in city street riding, starts uphill and tight turn exits with a passenger. That is why Malossi has fine tuned the Maxi Wing Clutch Bell to protect your clutch. We must not discard the fact that the finned reinforcement ring is also a safeguard against failure. It has been designed to resist the elevated centrifugal forces due to large rotational speeds generated by high performance engines. Keep in mind that centrifugal force increases by the square of the rotational speed. TECHNICAL SPECIFICATIONS Bell housing made of ductile steel and deep drawn Spline hub made of special steel, machined, welded and broached Frictional working surface machined to tight tolerances Dynamically balanced Nitride surface hardened. Cross reference Malossi 7717969B (was 7714329).

Fitment Chart

BENELLIBENELLI 400 VELVET 4T - MORINI MOTORMALOSSI 150mm CLUTCH BELL
BENELLIBENELLI 400 VELVET 4T - MORINI MOTORMALOSSI 150mm CLUTCH BELL
MALAGUTIMALAGUTI MADISON 400MALOSSI 150mm CLUTCH BELL
MALAGUTIMALAGUTI MADISON 400MALOSSI 150mm CLUTCH BELL
SUZUKISUZUKI 400 BURGMAN - AN400 - 1998-2002MALOSSI 150mm CLUTCH BELL
SUZUKISUZUKI 400 BURGMAN - AN400 - 1998-2002MALOSSI 150mm CLUTCH BELL
SUZUKISUZUKI 400 BURGMAN - AN400 - 2003-2006MALOSSI 150mm CLUTCH BELL
SUZUKISUZUKI 400 BURGMAN - AN400 - 2003-2006MALOSSI 150mm CLUTCH BELL
